PCB

HOME > Products > Equipment > PCB

Drilling

UV drilling system
4000U

  • 4000U is used for various materials such as PCB, metal, film and etc.
    It adopts the sheet/roll to roll typed loading/unloding system.
    The best quality and higher productivity can be achieved with flying control technology.
UV drilling system/4000U

UV drilling system
5000U

  • UV laser drilling system (5000U) is designed for fine hole processing by applying Neo scan system .
    It has high-speed productivity compared to a general galvo scanner tool.
    High quality can be achieved with a precise size beam and scanner control function.
UV drilling system/5000U

CO2 drilling system
5000C/6000C

  • CO2  laser drilling system uses the cutting-edge optics technology.
    It is applied to HDI, PKG and high quiality via hole process with a precise size beam and scanner control function.
CO2 drilling system:5000C/6000C

ITS drilling system
PCD

  • PCD is for carving 2D code through CCL disk holes, which is good for ITS (Information Tracing System) management.
ITS drilling system:PCD

Marking

Panel marking system
PGM/PUM

  • PGM/PUM is a high-quality laser marker for PCB panels.
    It is equipped with automated loader/unloader and vision inspection system.
    It has some optional items such as ITS reading, flipper functions.
    It is used for marking lot number, strip number, logo, and 1D/2D data code.
Panel marking system:PGM/PUM
